NHU2XL gPV 200A/1500V DC UL Rastalni uložak

ETI kod:: 004110612
Tip osigurača:: NH-U
Veličina:: NH2XL
Nazivna struja:: 200 A
Karakteristika:: gPV
Indikator:: Indikator statusa gornjeg osigurača
Nazivni DC napon:: 1500 V
DC Prekidna moć:: 30 kA
L/R:: 3 ms
Raspodjela snage (0,7xIn):: 15,9 W
Pd:: 36 W
Džulov integral prije el.luka (A2s):: 42.000
Radni Džulov integral (A2s):: 75.000
UL certifikat:: E347771
Standardi:: IEC 60269-6, UL 248-19
Primjena:: Osigurač za DC primenu

Pribor

Proizvod

Težina: 1.350 g
Net width: 60 mm
Net height: 198 mm
Net depth: 60 mm
Stock unit of measure: pcs

Osnovno pakovanje

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895737377
Basic packaging weight: 1,35 kg
Basic Packaging Dimensions Height: 0,064 m
Basic Packaging Dimensions Width: 0,222 m
Basic Packaging Dimensions Depth: 0,089 m
Basic packaging volume: 0,001 m³

Transportno pakovanje

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895737384
Transport packaging weight: 16,55 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 624 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 2XL
Power loss at rated current: 36 W
Rated switching capacity DC: 30 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 200 A
Rated voltage DC: 1.500
Utilization category: gPV (photovoltaic protection)
